Dimensions without packing: • Height : 35.4"
• Width : 15"
• Depth : 29.9"
• Weight with TCDU V : 145.6 lbs
Dimensions with packing: • Height : 44.1"
• Width : 18.5"
• Depth : 33.7"
• Weight with TCDU V : 172.8 lbs
Power Requirements: • 110/220 VAC ±10%, 50/60 Hz, 145 Watts
Temperature and Humidity: • In storage: 32°F - 104°F (0°C ~ 49°C)
• While operating: 45°F - 95°F (5°C ~ 35°C)
Allowable Humidity: • In storage : 10% < RH < 90%, non-condensed
• While operating : 15% < RH < 85%, non-condensed

Integrated Illuminated Sign: • High Visiblility LED Sign
• Attract Customers
LCD Screen: • 7 inch diagonal 32-bit color
• Backlit TFT LCD panel
• 800x480 Resolution
• Customizable Ad Screens
Printer: • 56mm (2" standard)
PIN Entry Device: • 16-key alphanumeric keypad
• PCI/Interac Certified
• Triple-DES (TDES) compliant EPP
Rear Service Panel: • Optional rear service panel
Communication: • 56Kb Internal Model
• TCP/IP Ethernet - SSL
CPU: • Coretex-A9 Dual Core
• DDR3 1Gbytes
• 512MBytes NAND Memory
• Windows CE 7.0
Card Reader: • DIP Type card reader
• EMV Optional
ADA: • Voice Guidance
• Lighted Transaction Guidance
• Accessible Keypad Layout
Security: • UL291 Business Hours Vault
• Electronic Locks
• A series Lock
• Kaba MasCencon Locks
Cash Dispenser: • 800 Note Fixed Cassette (TCDU)
• 2000 Note Rear-Load Removable Cassette
